KX6+2C Cable

Description

KX6 + 2C, CCTV Cable is used for the data transmission and function of CCTV camera. The addition of power cord on the basis of KX6 coaxial cable will reduce the repeated wiring steps when installing CCTV camera, optimize the installation method and improve the installation efficiency....

Chat Now Send Inquiry

Specification Download

Product Details

Download specification

Inquiry

Our strengths:

1. Old qualifications and good faith in business. Founded in 2018, our company has rich industry resources and experience, and has always made the market with "quality" and "reputation". Take "quality" and "reputation" as the life of the enterprise. Establish a good reputation in the market and customers.

2. Advanced quality, supervision, technology and service. The company has advanced manufacturing and testing equipment in the industry to test each batch of products, and has special quality inspectors to test each batch of products and provide all-round pre-sales, in-sales and after-sales services to each customer.

We are a manufacturer specializing in the production of coaxial cables. With many years of professional production, we can process and produce according to the different needs of customers.

Our factory is located in Lin'an, Zhejiang Province, China's cable production base. In terms of raw material supply, we have a complete industrial chain and many years of strategic partners in raw material supply, which can give us preferential prices in purchasing raw materials and have strong advantages over other regions;

Our factory is located in the suburbs. The annual rent cost and personnel cost can be saved a lot;

Moreover, our cable production industry has advanced production equipment, which not only greatly improves the production efficiency and product quality of our products, but also greatly saves our effective resources. Taken together, we can provide a competitive price advantage in this industry. Our guarantee: our products will undergo a series of strict inspections before packaging and delivery, which enables our customers to purchase products with confidence. Ensure that our customers are assured of our product quality.

Looking forward to working with friends all over the world!

Construction

Conductor	Material	BC
Conductor	Diameter	7 x ( 0.2mm ± 0.02 mm )
Insulation	Material	SPE
Insulation	Diameter	3.7 mm ± 0.2 mm
AL Foil	Construction	With Foil
	Material	APG
	Width	14 mm
	thickness	> 0.024 mm
	Overlap Rate	≥ 20%
Braid	Material	BC / CCA
	Diameter	0.12 mm
	Braid Coverage	60% - 98%
Jacket	Material	PVC
Jacket	Diameter	6.1 mm ± 0.3 mm
Power Conductor	Material	BC / CCA
Power Conductor	Diameter	24 x ( 0.2 mm ± 0.02 mm )
Power Insulation	Material	HDPE
Power Insulation	Diameter	2 x ( 1.65 mm ± 0.02 mm )
Out Jacket	Material	PVC
Out Jacket	Diameter	8.1 mm ± 0.3 mm

Packing

Package length	100m / 300m / 500m
	Customized
Box type	Ordinary / Waterproof
	Customized optional

Test Data

Dielectric Strength	Not breakdown with 2kV DC for 1 min
Sheath Strength	Not breakdown with 3kV
Characteristic Resistance	75Ω ± 5Ω
Insulation Resistance	5000MΩ/km
Elongation at Break (Wire)	≥15%
Elongation at Break (Sheath)	≥150%
Low Temperature Bending	Not cracked
Thermal Shock	Not cracked
Operating Temperature	–20°C to +60°C (–4°F to 140°F)
Storage Temperature	–10°C to +40°C (14°F to 104°F)
